YZW360
结构特性Structure Characteristics
|
Structure Characteristics |
||
|
Structure |
Item |
Standard Value |
|
Inner Conductor |
Material |
Silver Plated Copper |
|
Construction (mm) |
1/0.53 |
|
|
Nom.Dia (mm) |
0.53 |
|
|
Insulation |
Material |
PTFE |
|
Nom.Dia (mm) |
1.68 |
|
|
Inner shield |
Material |
SC Foil |
|
Nom.Dia (mm) |
1.88 |
|
|
Innerlayer |
Material |
Round Silver Plated Copper Braided Wire |
|
Nom.Dia (mm) |
2.25 |
|
|
Outer shield |
Material |
Round Silver Plated Copper Braided Wire |
|
Nom.Dia (mm) |
2.65 |
|
|
Jacket |
Material |
High Performance Thermoplastic Elastomer |
|
Nom.Dia (mm) |
3.56 |
|
电性能参数
|
Item |
Standard Value |
Attenuation and Power handing@25℃&Sea Level |
||
|
Impedance（Ω） |
50 |
Frequency (MHz) |
Attenuation (dB/100m) |
Power handing (W) |
|
Capacitance（pF/m） |
95 |
0.5 |
46.47 |
288 |
|
1 |
66.57 |
201 |
||
|
Velocity of Propagation |
70% |
3 |
119.00 |
112 |
|
4 |
138.98 |
96 |
||
|
Max Operating Frequency（GHz） |
61 |
6 |
173.43 |
77 |
|
8 |
203.38 |
66 |
||
|
Screening Effectiveness（dB） |
＞110 |
10 |
230.47 |
58 |
|
12 |
255.52 |
52 |
||
|
Dielectric Withstanding Voltage(V@DC) |
1000 |
18 |
322.60 |
41 |
|
26.5 |
405.03 |
33 |
||
|
Phase Change VS Bending（°/GHz） |
±0.3 |
40 |
519.35 |
26 |
|
K1 |
63.64829396 |
|||
|
Phase Change VS Temperature@（-45~+85）℃ |
N/A |
K2 |
2.919947507 |
|
|
IL=K1*√FMhz+K2*FMHz |
||||
机械和环境性能
|
Mechanical &Environmental Characteristics |
Replaceable Type |
||
|
|
9.5 mm |
|
|
|
|
19.0 mm |
|
|
|
|
28 g/m |
|
|
|
|
-55~ +125℃ |
|
|
